Beam Forklift With Adjustable Lifting Height And Speed
Electric Stacker Forklift is widely applied in warehouses, factories, logistics hubs, and production lines. It is ideal for handling double-face pallets and operating in narrow aisles. The machine features high lifting efficiency, easy operation, and a smart power system, which significantly reduces labor costs and enhances productivity.
| Model: | HY-1025 / HY-1030 / HY-1525 / HY-1530 |
|---|---|
| Load Capacity (Kg): | 1000 / 1000 / 1500 / 1500 |
| Load Center (mm): | 500 |
| Max. Lifting Height (mm): | 2500 / 3000 / 2500 / 3000 |
| Free Lift (mm): | 0 |
| Wheel Type: | Polyurethane Solid Tire |
| Pedal Length (mm): | 500 |
| Fork Size (L×W) (mm): | 1150 × 190 |
| Width Between Forks (mm): | 680 |
| Overall Length (Pedal Closed) (mm): | 2040 |
| Overall Width (mm): | 850 |
| Overall Height (Mast Closed) (mm): | 1805 / 2055 / 1805 / 2055 |
| Overall Height (Fork Raised, with Backrest) (mm): | 3036 / 3536 / 3036 / 3536 |
| Outside Turning Radius (mm): | 1725 |
| Front Wheel to Fork Tip (mm): | 330 |
| Aisle Width for Pallet 800×1200 (Lengthways) (mm): | 2480 |
| Aisle Width for Pallet 1000×1000 (Crossways) (mm): | 2460 |
| Lift Speed (Laden/Unladen) (mm/s): | 70 / 108 |
| Lowering Speed (Laden/Unladen) (mm/s): | 78 |
| Battery Weight (Kg): | 200 |
| Max. Walking Speed (Km/h): | 4.0 / 5.8 |
| Gradeability (%): | 8 |
| Total Weight (With Battery) (Kg): | ~935 / ~950 / ~940 / ~950 |
| Driving Wheel (mm): | Φ215 × 75 |
| Front Wheel (mm): | Φ80 × 70 |
| Balance Wheel (mm): | Φ150 × 50 |
| Battery (V/Ah): | 24 / 210 |
| Charger (V/A): | 24 / 30 |
| Driving Motor Power (Kw): | 1.5 |
| Lifting Motor Power (Kw): | 2.0 |
| Battery Dimensions (mm): | 650 × 200 × 585 |
