Normal Temperature Dyeing Machine with Adjustable Process Parameters and 50kg/Time or 100kg/Time Capacity
| Brand Name: | HHD |
| MOQ: | 1set |
| Price: | 1000–200000USD |
| Packaging Details: | Export Packaging |
| Payment Terms: | T/T 50% in advance,50% before shipment |
Detail Information
Place of Origin:
Guangdong Province
Applications:
Apparel, Footwear,Industrial Manufacturing
Automation Level:
Semi-automatic
Control System:
Touch Screen/ Button Operation
Frame Material:
High-Strength Steel
Control Method:
Electronic Control + Manual Adjustment
Noise Level:
≤ 80 DB
Humidity Range:
≤ 85% RH
Delivery Time:
Within 20 days after downpayment
Supply Ability:
150 sets / month
Highlight:
100kg/Time normal temperature machine
,50kg/Time normal temperature machine
,Semi automatic normal dyeing machine
Product Description
50kg/Time 100kg/Time Normal Temperature Dyeing Machine With Adjustable Process Parameters
The Normal Temperature Dyeing Machine is engineered for precision dyeing of various fiber materials including cotton tape, flax, wool, acrylic, man-made fibers, and blended twisted yarns. Ideal for small-batch processing where consistent color penetration is essential.
Key Features and Benefits
- Precision Reverse Turning Controller: Ensures alternating dye liquor flow for deep, uniform penetration into dense or twisted materials
- Intelligent Circulation System: Multi-speed belt pulley allows flow adjustment for different tape or yarn types
- Expandable System: Can operate in series (2-4 machines) to reduce variability and improve batch consistency
Corrosion-Resistant Stainless Steel Construction
- All dye-contact components made of high-grade stainless steel for durability
- High-efficiency stainless steel axial-flow pump with sealed mechanical device
- Special diversion block prevents dead zones for uniform dye circulation
Automated Dosing and Cleaning System
- Stainless steel dosing pumps for precise chemical addition
- Dosing barrel with agitating paddles and reverse cleaning system
- Convenient sampling port for process monitoring without disruption
- Premium imported valves, pipes, and electrical components for reliability
Technical Specifications
| Model | HY-VT009 | HY-VT009-1 |
|---|---|---|
| Machine Name | Normal Temperature Machine (50kg) | Normal Temperature Machine (100kg) |
| Average Output | 50 kg / time | 100 kg / time |
| Max Temperature | 100 ℃ | 100 ℃ |
| Power | 30 kW | 50 kW |
| Voltage | 380 V | 380 V |
| Machine Size (mm) | 900 × 900 × 2100 | Φ1700 × 900 × 2100 |
| Carrier Size (mm) | 800 × 800 × 1200 | 1500 × 800 × 1200 |
| Weight (kg) | 1800 | 2500 |
