10-25m/Min Hook And Loop Back Adhesive Machine With Adjustable Heat And Pressure For Apparel And Footwear
| Brand Name: | HHD |
| MOQ: | 1set |
| Price: | 1000–200000USD |
| Packaging Details: | Export Packaging |
| Payment Terms: | T/T 50% in advance,50% before shipment |
Detail Information
Place of Origin:
Guangdong Province
Applications:
Apparel, Footwear,Industrial Manufacturing
Automation Level:
Semi-automatic
Control System:
Touch Screen/ Button Operation
Frame Material:
High-Strength Steel
Control Method:
Electronic Control + Manual Adjustment
Noise Level:
≤ 80 DB
Humidity Range:
≤ 85% RH
Delivery Time:
Within 20 days after downpayment
Supply Ability:
150 sets / month
Highlight:
25m/Min Back Adhesive Machine
,10m/Min Hook And Loop Back Adhesive Machine
,Hook And Loop Back Adhesive Machines
Product Description
10-25m/Min Hook And Loop Back Adhesive Machine With Adjustable Heat And Pressure
Reliable Hook And Loop Back Adhesive Machine with Adjustable Heat and Pressure
This hot melt glue back gluing machine is specially designed for the back gluing process of hook & loop tapes and similar narrow fabric materials. It is equipped with a PLC control system and intelligent controls to ensure efficient and stable operation.
Key Features
- Advanced tension control for stable feeding and high-accuracy operation
- Precise speed regulation and length setting capabilities
- Automatic cutting function reduces manual intervention
- Torque winding control system for smooth and neat rewinding
- Efficient hot melt glue system ensures firm adhesion and smooth surface finish
- User-friendly interface with modular structure for easy maintenance
- Ideal for both large-scale production and customized production lines
Technical Specifications
| Model | HY-VT200 |
|---|---|
| Linear Speed | 10～25 m/min |
| Max. Tension of Yarn | 500 N |
| Tape Quantity | 1 pc |
| Max. Width | 200 mm |
| Production Capacity | 50-85 kg/h |
| Usable Area | 20 m * 1 m |
| Principal Motor Power | 10 kW |
| Control System | Transducer Control |
| Air Pressure | 6 bar |
