High Speed Nylon Zipper Core Line Making Machine with 8 Axis and 16 Axis Configurations and 1.5–3.0 kW Motor Power
| Brand Name: | HHD |
| MOQ: | 1set |
| Price: | 1000–20000USD |
| Packaging Details: | Export Packaging |
| Payment Terms: | T/T 50% in advance,50% before shipment |
Detail Information
Place of Origin:
Guangdong Province
Applications:
Apparel, Footwear,Industrial Manufacturing
Automation Level:
Semi-automatic
Control System:
Touch Screen/ Button Operation
Motor Power:
1.5–3.0 KW
Frame Material:
High-Strength Steel
Control Method:
Electronic Control + Manual Adjustment
Maintenance Cycle:
Recommended Every 500 Hours
Delivery Time:
Within 20 days after downpayment
Supply Ability:
150 sets / month
Highlight:
High Speed Core Line Making Machine
,8 Axis Core Line Making Machine
,16 Axis nylon zipper making machine
Product Description
High Speed Nylon Zipper Core Line Making Machine 8 Axis 16 Axis
The Automatic PLC digital system control device ensures intelligent, precise, and stable performance throughout the production process. The system features high automation and requires minimal manual intervention, improving overall production efficiency and consistency.
The twist adjustment is extremely simple—it does not require gear replacement, allowing for rapid reconfiguration. This flexible design supports fast adjustments to twist specifications, accommodating various product requirements with ease.
The machine achieves high-output merging and twisting, efficiently completing lump-sum twisting in a single process. During operation, the twisted threads are even, strong, and aesthetically refined, making it ideal for producing premium-quality zipper or textile threads.
- Equipped with thread breaking sensors, the machine can detect anomalies, automatically shut down, and retain memory functions, reducing material waste and downtime.
- It also supports independent single-spindle operation on both sides, enabling the machine to process different materials and twist specifications simultaneously—ideal for diversified production.
- With a low failure rate, low noise, and a user-friendly structure, the machine is easy to operate, maintain, and repair.
- Its robust structure and high-quality components ensure long service life, and all spare parts are readily available to support ongoing maintenance.
Machine Technical Data
| Specification | 8-axis | 16-axis |
|---|---|---|
| Main motor power | 1.9 kW | 3 kW |
| Voltage | 380 V | 380 V |
| Net weight | 400 kg | 500 kg |
| Gross weight | 500 kg | 600 kg |
| Machine size | 185×80×165 cm³ | 220×80×165 cm³ |
| Packing size | 190×100×185 cm³ | 225×100×185 cm³ |
Production Capacity
| Zipper size | 8-axis (tons/month) | 16-axis (tons/month) |
|---|---|---|
| No.3 | 5 | 2.5 |
| No.4 | 7 | 3.5 |
| No.5 | 9 | 4.5 |
| No.7 | 10 | 5 |
| No.8 | 10 | 5 |
| No.9 | 11 | 5.5 |
| No.10 | 11 | 5.5 |
